Reverse RDP Attack: The Hyper-V Connection(Vulnerability)
Earlier this year, we published our research on the Reverse RDP Attack. In our previous blog post, we described how we found numerous critical vulnerabilities in popular Remote Desktop Protocol (RDP) clients. However, our research didn’t just end there. In this blog post, we discuss new developments, including a new target: Microsoft’s Hyper-V.
TL;DR – The Path-Traversal vulnerability we found in Microsoft’s RDP client is also applicable as a guest-to-host VM escape in Hyper-V Manager. Following this revelation, Microsoft issued a CVE (CVE-2019-0887), and released a patch for the vulnerability.
Hyper-V? It isn’t an RDP client
Microsoft’s Hyper-V is a virtualization technology that is used in Microsoft’s Azure cloud, and offered as a virtualization product on top of the Windows 10 operating system. Similar to other virtualization technologies, Hyper-V comes with a graphical user interface that lets a user manage the local / remote virtual machine (VM).
After this short lesson on Hyper-V, the question remains: What does Hyper-V have to do with RDP? The answer is found in the term “enhanced sessions”, which are Microsoft’s equivalent of VMWare’s VM tools. Enhanced sessions offer a user an extended functionality that includes clipboard synchronization between the guest and the host. As you may recall, we already found a Path-Traversal vulnerability in the clipboard synchronization implemented by Microsoft’s RDP client. It’s time to check if the same vulnerability will also work out-of-the-box for the Hyper-V case.
To perform the tests, we installed Hyper-V on our machine, and converted our initial virtual machine into a Hyper-V machine. We then used the Hyper-V Manager program and connected to our virtual machine. Soon enough, we encountered the familiar Settings window seen in Figure 2.
As we can see, this is exactly the same GUI window that is also used for the settings of an RDP connection when using mstsc.exe. This looks promising. To top it off, the Clipboard resource is shared by default, meaning this is an enhanced session. Feeling motivated, we ran the same script we initially submitted to Microsoft in the mstsc.exe case, and it worked. We just found a Hyper-V guest-to-host VM escape over the control interface, using the RDP vulnerability! Here is a video of a paste-only attack for the Hyper-V scenario:
RDP & Hyper-V – Explained
It turns out that RDP is used behind the scenes as the control plane for Hyper-V. Instead of re-implementing screen-sharing, remote keyboard and a synchronized clipboard, Microsoft decided that all of these features are already implemented as part of RDP, so why not use it in this case as well? In our joint BlackHat presentation with Dana Baril from Microsoft, we elaborate more on yet another Virtualization-based security isolation technique, and the custom version of RDP that it relies on.
While it was hard for any security researcher to miss Microsoft’s effort to test and improve the security of its Hyper-V technology, we can learn an important lesson from this research. As the saying goes: your system is only as strong as its weakest link. In other words, by depending on other software libraries, Hyper-V Manager inherits all of the security vulnerability that are found in RDP, and in any other software library that it uses.
Although the lesson might sound trivial, the problem of updating versions and keeping track of vulnerabilities in external software dependencies is known to be a notoriously hard one.
This time, however, it seems that Microsoft decided to fix the vulnerability. Immediately after we disclosed the Hyper-V implications of the vulnerability to MSRC, we got a reply that they will once again look at it. A few weeks later, a new MSRC ticket was opened for it, later leading to an official CVE, CVE-2019-0887, and a patch. Before we start analyzing the patch, let’s recap the vulnerability. A malicious RDP server can send a crafted file transfer clipboard content that will cause a Path-Traversal on the client’s machine. Therefore, we expect to see that mstscax.dll will check the received FileGroupDescriptorW clipboard format, and sanitize each file path that is contained inside.
Now that there is a patch for the Path-Traversal vulnerability, we highly recommend all users to install the patch to protect both their RDP connections and their Hyper-V environment. Our research shows a researcher can never know if a given research project has reached its end. After we “finished” the RDP research (with mixed feelings), the feedback we received from the research community helped us discover the full implications of the vulnerabilities we found, which lay way beyond the initial RDP scope of our research.
